詳細說明
型號規格
| WSL-5000-A -5000-B -5000-C | WSL-6000-A -6000-B -6000-C | WSL-8000-B -8000-C -8000-D | WSL-10000-B -10000-C -10000-D -10000-E | WSL-12000-B -12000-C -12000-D -12000-E | WSL-16000-B -16000-C -16000-D -16000-E | WSL-18000-E -18000-F -18000-G -18000-H | WSL-21000-E -21000-F -21000-G -21000-H | WSL-24000-E -24000-F -24000-G -24000-H | |||||||||
額定載荷 (kg) | 2250 | 2700 | 3600 | 4500 | 5400 | 7200 | 8100 | 9450 | 10800 | |||||||||
功率 | 3.7 | 3.7 | 7.5 | 11.5 | 15 | 15 | 15 | 15 | 15 | |||||||||
平臺尺寸 (mm) | 1270x2130 1524x2438 1524x3048 | 1524x2130 1524x2438 1524x3048 | 1727x2438 1727x3048 1727x3810 | 1727x2438 1727x3048 1727x3810 1727x4267 | 1727x2438 1727x3048 1727x3810 1727x4267 | 1727x2438 1727x3048 1727x3810 1727x4267 | 1727x3810 1727x5486 1727x6409 1727x7315 | 1727x3810 1727x5486 1727x6409 1727x7315 | 1727x3810 1727x5486 1727x6409 1727x7315 | |||||||||
平臺最低高度 | 92 | 92 | 98 | 100 | 100 | 100 | 100 | 100 | 100 | |||||||||
圍欄高度 (mm) | 1092 | 1092 | 1117 | 1117 | 1117 | 1117 | 1117 | 1117 | 1117 | |||||||||
總長 (mm) | 3708 4013 4724 | 3708 4013 4724 | 4216 4826 5588 | 4216 4826 5588 6045 | 4216 4826 5588 6045 | 4216 4826 5588 6045 | 6045 7440 8355 2970 | 6045 7440 8355 2970 | 6045 7440 8355 2970 | |||||||||
總寬 (mm) | 2210 | 2210 | 2460 | 2590 | 2590 | 2590 | 2590 | 2590 | 2590 | |||||||||
重量 (mm) | 1400 1675 2038 | 1460 1740 2105 | 1935 2735 3330 | 2840 3665 3990 4342 | 3352 3710 3390 4342 | 3474 3757 4264 4912 | 6028 7326 8300 9272 | 6325 7703 8685 9628 | 6745 8174 9189 10160 | |||||||||
導向板尺寸 (mm) | 1219 or 1727 | 1219 or 1727 | 1320 or 1828 | 1320 or 1828 | 1320 or 1828 | 1320 or 1828 | 1320 or 1828 | 1320 or 1828 | 1320 or 1828 | |||||||||
包轉后長度 (mm) | N/A 3556 4165 | N/A 3556 4165 | 3937 4546 5308 | 3937 4572 5334 5791 | 3937 4572 5334 5791
| 3937 4572 5334 5791 | 3937 4572 5334 5791 | 3937 4572 5334 5791 | 3937 4572 5334 5791 | |||||||||
包裝后寬度 (mm) | N/A 2870 2870 | N/A 2870 2870 | 3073 | 3073 | 3073 | 3073 | 3073 | 3073 | 3073 | |||||||||
